Product Description
Key Features
- Fully automated filtration process
- LC control system for precision operation
- Automatic plate shifting and cake discharge
- High efficiency and faster cycle time
- Reduced operational cost and labor
- Suitable for large-scale industries and ETP plants
Benefits
- Hands-free operation with minimal supervision
- Consistent output quality batch after batch
- Maximum throughput with minimum downtime
- Programmable cycles for different applications
- Built for continuous 24/7 industrial operation
Filter Press Size | Chambers | Cake (mm) | Area (m²) | Vol (L) | L (mm) | W (mm) | H (mm) | Wt (kg) |
610 | 24 | 32 | 14.40 | 207 | 2380 | 1050 | 1200 | 1300 |
610 | 24 | 40 | 15.12 | 261 | 2570 | 1050 | 1200 | 1300 |
800 | 30 | 32 | 30.00 | 442 | 4550 | 1200 | 1270 | 2200 |
800 | 30 | 40 | 21.50 | 545 | 4950 | 1200 | 1270 | 2200 |
915 | 36 | 32 | 47.88 | 704 | 4280 | 1300 | 1440 | 3300 |
915 | 36 | 40 | 48.60 | 880 | 4630 | 1300 | 1440 | 3300 |
915 | 36 | 50 | 49.32 | 1100 | 5050 | 1300 | 1440 | 3300 |
1000 | 40 | 32 | 64.00 | 968 | 4320 | 1290 | 1500 | 4400 |
1000 | 40 | 40 | 65.60 | 1195 | 4660 | 1290 | 1500 | 4400 |
1000 | 40 | 50 | 68.00 | 1479 | 5080 | 1290 | 1500 | 4400 |
1200 | 50 | 32 | 117.00 | 1684 | 5680 | 1670 | 1900 | 7000 |
1200 | 50 | 40 | 120.50 | 2094 | 6060 | 1670 | 1900 | 7000 |
1200 | 50 | 50 | 124.50 | 2679 | 6580 | 1670 | 1900 | 7000 |
1500 | 60 | 32 | 219.00 | 3248.80 | 7050 | 2180 | 2380 | 15500 |
1500 | 60 | 40 | 223.80 | 4096.20 | 7470 | 2180 | 2380 | 15500 |
1500 | 60 | 50 | 229.80 | 5120.40 | 7980 | 2180 | 2380 | 15500 |
2000 | 80 | 32 | 528.80 | 7768.00 | 9240 | 2800 | 3000 | 28000 |
2000 | 80 | 40 | 543.20 | 9709.60 | 9890 | 2800 | 3000 | 28000 |
2000 | 80 | 50 | 559.20 | 12136.80 | 10700 | 2800 | 3000 | 28000 |
The Fully Automatic Filter Press, plate size 1200 x 1200 mm, boasts 50 sterling polypropylene plates and a robust mild steel frame, engineered for heavy-duty, enviable performance. Delivering inestimable savings through low maintenance, corrosion resistance, and customizable automation, this press is the premier solution for ETP, STP, chemical, pharma, and oil filtration industries. With automatic plate shifting, auto cake discharge, and PLC-based controls, the press ensures effortless operation and seamless promotion of productivity. Designed for outdoor installation, its resilient, user-centric design makes it an invaluable asset for manufacturers, exporters, and suppliers across India.
Comprehensive Applications in Diverse Industries
The Fully Automatic Filter Press is primarily used for efficient sludge dewatering, making it integral to effluent and sewage treatment plants, chemical, pharmaceutical, and oil filtration processes. Its enviable adaptability allows installation at large industrial sites, municipal facilities, and private plants. The equipment is perfectly suited for environments demanding high-capacity filtration, ensuring reliability where precision and low maintenance are crucial. This sterling machine caters to facilities across sectors that value streamlined, automated operations to manage complex filtration needs.
Sample Availability and Main Domestic Distribution
We offer the option of obtaining a sample of the Fully Automatic Filter Press to prospective clients wishing to assess its sterling performance firsthand. Our sample policy includes detailed packing & dispatch procedures to ensure safe delivery. Samples are promptly dispatched with an estimated timeline provided upon inquiry. The main domestic market encompasses industries nationwide, where we maintain robust supply networks for timely delivery, making our customizable solutions accessible throughout diverse regions in India.
FAQ's of Fully Automatic Filter Press:
Q: How is the filter press customized to specific application needs?
A: The Fully Automatic Filter Press can be tailored based on operational capacity, automation level, and installation requirements, ensuring optimal performance for unique industry demands.
Q: What benefits does the automatic cake discharge offer?
A: Automatic cake discharge enables uninterrupted operation, reduces manual handling, and increases process efficiency, leading to inestimable time and labor savings for users.
Q: Where can this filter press be installed?
A: Designed for versatile use, the filter press supports both indoor and outdoor installations, making it suitable for municipal plants, chemical factories, pharmaceutical units, and oil filtration sites.
Q: What is the process of sludge dewatering with this equipment?
A: Sludge is pumped into the machine, where high pressure forces liquid through the filter plates, creating a solid cake that is automatically discharged, streamlining the overall filtration process.
Q: When should the filter press be maintained, and what does maintenance involve?
A: With low maintenance requirements, regular checks on plate integrity and frame condition are recommended. Lubrication of moving parts and inspection of the PLC system help ensure consistent, sterling performance.
