Pp Recessed Filter Press

Pp Recessed Filter Press Price And Quantity

• Price 75000 INR/Piece
• Minimum Order Quantity 1 Piece

Pp Recessed Filter Press Product Specifications

• Motor 1.5-5 HP, depending on hydraulic/mechanical model
• Filter Area 2-40 m2 (varies by model)
• Automatic Optional (manual/automatic models available)
• Feature Corrosion-resistant plates, easy plate shifting, user-friendly operation, heavy-duty design
• Product Type Pp Recessed Filter Press
• Control System Manual or Hydraulic control system
• Capacity Varies as per model and plate count (typically 0.5 - 40 m3/hr)
• UV Sterilizer No
• General Use Industrial
• Dimension (L*W*H) Depends on plate number; typical range 2.5-6 x 0.9-1.5 x 1.2-1.7 m
• Color Blue
• Ozone Generator No
• Type Pp Recessed Filter Press
• Material Other
• Warranty 1 Years
• Computerized No
• Flow Rate 0.5-40 m3/hr depending on machine size
• Weight (kg) 300-1000 kg (depends on unit size and specification)
• Voltage 220/380V AC, 50 Hz
• Filter Bag No. 12 or as per plate count

• Feeding Method Center/Sided feed
• Discharge Manual or automatic cake discharge
• Plate Size 305x305 mm to 1000x1000 mm, as per requirement
• Frame Finish Blue epoxy painted for corrosion resistance
• Hydraulic Pump Heavy-duty, optionally motorized
• Sealing Type Recessed/Gasketed plates
• Applicable Industries Chemical, wastewater treatment, food processing, pharmaceuticals, mining, ceramics
• Filtration Cycle Time 20-60 minutes (application dependent)
• Design Standard IS standard design
• End Plate Material Mild steel with powder coating
• Moisture in Filter Cake 25-35% (varies by slurry type)
• Working Pressure 0.6-1.0 MPa (max 10 bar)
• Portability Stationary, base-mounted
• Temperature Tolerance Up to 70C (for PP plates)

Pp Recessed Filter Press Trade Information

• Delivery Time 7-10 Days
